Description
TIP-ON BLUMOTION combines the advantages of the TIP-ON mechanical opening system with tried and tested soft-close BLUMOTION.
Touch to open.
Close with an energetic push (the TIP-ON function is activated and BLUMOTION cuts in for soft and effortless closing).
What’s more, it works on a purely mechanical basis.
Includes Linkage Rod (1125mm)
There are five units to select from, depending on length of runner and weight of drawers
Type S0. For 270 – 300mm runners. Total weight of pull out 0 – 10kg
Type S1. For 270 – 300mm runners. Total weight of pull out 10 – 20kg
Type L1. For 350 – 600mm runners. Total weight of pull out 0 – 20kg
Type L3. For 350 – 550mm runners. Total weight of pull out 15 – 40kg
Type L5. For 450 – 600mm runners. Total weight of pull out 35 – 60kg
Link to Assembly Instructions
